STEVAL-ISB034V1

Part No STEVAL-ISB034V1
Manufacturer STMicroelectronics
Catalog Evaluation Boards - Linear Voltage Regulators
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - Linear Voltage Regulators
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Channels per IC 1 - Single
Voltage - Output 2.5V
Current - Output 200mA
Voltage - Input 2.85V ~ 5.5V
Regulator Type Positive Fixed
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part LDBL20
Other Names 497-16458
Standard Package 1
RoHS Status Not applicable
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1283811-STEVAL-ISB034V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISB034V1 CAD Model

Description

STEVAL-ISB034V1 - Wireless Charging Transmitter Evaluation Board

The STEVAL-ISB034V1 from STMicroelectronics is a state-of-the-art evaluation board designed as a wireless charging transmitter, which is based on the STWBC-EP digital controller for Qi-compliant wireless charging applications. This evaluation board is perfect for developers looking to create or integrate wireless power solutions into a variety of applications, ranging from portable electronics to battery charging systems.

The board is capable of delivering up to 15 watts of power, ensuring fast and efficient charging for devices that support the Qi wireless charging standard. It operates at a fixed frequency and employs half-bridge or full-bridge inverter topologies, which are selectable depending on the desired application. The STEVAL-ISB034V1 is equipped with a USB interface for firmware updates, making it easy to keep the board up-to-date with the latest features and improvements.

One of the key features of the STEVAL-ISB034V1 is its Foreign Object Detection (FOD) functionality, which enhances safety by preventing power transfer when a metal object is detected between the transmitter and receiver. This feature ensures that the system operates safely and efficiently, protecting both the device and the user.

The evaluation board also includes an I²C interface, which allows for communication with the digital controller and provides access to a full set of configurable parameters. This flexibility enables developers to fine-tune their applications for optimal performance. Additionally, the board is equipped with LED indicators that provide visual feedback on the charging status and error conditions, making it user-friendly and easy to diagnose issues.

The STEVAL-ISB034V1 is an excellent tool for R&D professionals and hobbyists alike, offering an easy-to-use platform for experimenting with wireless charging technology. With the support of comprehensive documentation and STMicroelectronics' design ecosystem, this evaluation board is a valuable asset for anyone looking to explore the capabilities and potential of wireless power transfer.
