EC2-5NU Real Image EC2-5NU real image3736 EC2-5NU real image3737 EC2-5NU real image3738 EC2-5NU Real Image1 EC2-5NU Real Image2 EC2-5NU Real Image3 EC2-5NU Real Image4 EC2-5NU Real Image5 EC2-5NU Real Image6
Same model may have multiple batches, images only for reference.
EC2-5NU Real Image EC2-5NU real image3736 EC2-5NU real image3737 EC2-5NU real image3738 EC2-5NU Real Image1 EC2-5NU Real Image2 EC2-5NU Real Image3 EC2-5NU Real Image4 EC2-5NU Real Image5 EC2-5NU Real Image6
EC2-5NU Real Image EC2-5NU real image3736 EC2-5NU real image3737 EC2-5NU real image3738 EC2-5NU Real Image1 EC2-5NU Real Image2 EC2-5NU Real Image3 EC2-5NU Real Image4 EC2-5NU Real Image5 EC2-5NU Real Image6
Same model may have multiple batches, images only for reference.

EC2-5NU

Part No EC2-5NU
Manufacturer Kemet
Catalog Signal Relays, Up to 2 Amps
Description RELAY GEN PURPOSE DPDT 2A 5V
Datasheet
EC2-5NU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Kemet
Packaging Tube/Rail
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 28mA
Coil Voltage 5VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 3.75 VDC
Turn Off Voltage (Min) 0.5 VDC
Operate Time 2ms
Release Time 1ms
Mounting Through Hole
Termination Style PC Pin
Coil Power 140 mW
Coil Resistance 178 Ohms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 090708-EC2-5NU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Automotive, Industrial, Power Management, Consumer Electronics, Portable Devices
Ultra Librarian 3D Model Ultra Librarian EC2-5NU CAD Model

Description

EC2-5NU Relay

The EC2-5NU is a versatile relay suitable for a broad spectrum of applications. Its design emphasizes durability and ease of integration into existing setups.

  • Features and Benefits:
    • High switching capacity
    • Compact footprint for seamless integration
    • Reliable switching action
    • Environmentally resilient construction
  • Applications:
    • Consumer electronics
    • Network servers
    • Agricultural machinery
  • Additional Details: This relay provides an optimal balance of quality and economy for demanding projects.
