SSD1963QL9

Part No SSD1963QL9
Manufacturer Solomon
Catalog HOT - SALES and EOL Components (S)
Description LCD Display Controller 128-Pin LQFP Tray
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Solomon
Win Source Part Number 340870-SSD1963QL9
Family Name SSD1963
Introduction Date December 08, 2008
Country of Origin Taiwan
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SSD1963QL9 CAD Model

Description

The SSD1963QL9 is a display controller manufactured by Solomon Systech. It's a popular choice for driving TFT LCDs with resolutions up to 800x480. It integrates features like a TFT LCD controller, backlight control, and touch screen interface support, making it suitable for a wide range of embedded applications.

Applications

  • GPS Devices: Used as the display driver in portable GPS navigation systems.
  • Handheld Instruments: Found in portable testing and measurement equipment with LCD displays.
  • Industrial Control Panels: Implemented in HMI (Human Machine Interface) systems for industrial automation.
  • Medical Devices: Drives the displays in certain types of medical equipment requiring a graphical user interface.
  • E-Readers: Can be used in e-reader devices to control the e-ink display.

Features

  • Supports up to 800x480 resolution TFT LCD panels.
  • Integrated TFT LCD controller.
  • Supports 16-bit and 24-bit RGB interfaces.
  • Built-in PWM for backlight control.
  • Supports touch screen interface.
  • Built-in PLL for clock generation.

Benefits

  • Simplified display interface reduces development time.
  • Integrated backlight control reduces external component count.
  • Touch screen support enables interactive applications.
  • High resolution support provides sharp and clear visuals.
  • Wide voltage range provides design flexibility.

Additional Details

The SSD1963QL9 simplifies the design of display systems by integrating multiple functions into a single chip. Its ability to handle various display sizes and color depths makes it versatile for a wide range of applications. The PWM backlight control allows for precise adjustment of the display brightness, optimizing power consumption and visual comfort. The integrated touch screen interface eliminates the need for external touch screen controllers, reducing the system cost and complexity. Detailed specifications on the device, its voltage requirements and register configurations are available in the datasheet. Using the specific parameters defined in the datasheet is crucial for optimal functionality and avoiding damage to both the controller and the connected display.
