Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Filter Type Butterworth, Low Pass Switched Capacitor
Frequency - Cutoff or Center 25kHz
Number of Filters 1
Filter Order 8th
Supply Voltage - Operating 4.75 V to 11 V, ±2.375 V to 5.5 V
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 110958-MAX291ESA+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX291ESA+ CAD Model

Description

Maxim Integrated's MAX291ESA+ Low-Power, 8th-Order, Continuous-Time Filters

The MAX291ESA+ is a compact, precision, 8th-order, low-pass, continuous-time filter that significantly reduces the complexity of signal conditioning in a wide array of applications. Manufactured by Maxim Integrated, a leader in analog and mixed-signal engineering, this filter is designed to process signals with minimal distortion, making it a perfect fit for anti-aliasing and reconstruction filters, noise reduction, and signal processing in a variety of electronic systems.

With its continuous-time operation, the MAX291ESA+ does not require an external clock, thereby eliminating the need for anti-aliasing preceding the filter and sample-and-hold circuits. This feature simplifies design and reduces system power consumption. The filter provides a sharp roll-off with a transition ratio of 1.5:1, ensuring that unwanted frequencies are effectively attenuated, preserving the integrity of the desired signal.

The MAX291ESA+ operates from a single +5V supply or dual ±5V supplies, offering flexibility in power supply design. Its low power consumption, typically 7.5mA, makes it an energy-efficient choice for portable and battery-powered devices. The device comes in a small 8-pin SO package, saving valuable board space and making it suitable for compact electronic products.

Featuring a fixed 50kHz cutoff frequency, the MAX291ESA+ provides a stable filtering characteristic that is independent of temperature and supply variations, ensuring reliable performance across various environmental conditions. This filter's easy-to-use interface requires no external components for setting the frequency, which streamlines the design process and accelerates time-to-market for products.

With its robust design, the MAX291ESA+ is designed to withstand electrostatic discharge (ESD) events, ensuring durability and longevity in the field. It is ideal for applications in data acquisition systems, industrial controls, communication systems, and medical electronics where precision and reliability are paramount.

In summary, the MAX291ESA+ from Maxim Integrated is a versatile, low-power filter that offers high-performance signal conditioning in a small footprint, making it a valuable component for designers looking to enhance their electronic systems.
