Products specifications

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Tube
Transistor Type 8 NPN Darlington
Current - Collector (Ic) (Maximum) 500mA
Voltage - Collector Emitter Breakdown (Maximum) 50V
Vce Saturation (Maximum) at Ib, Ic 1.6V at 500μA, 350mA
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 18-SOIC
Supplier Device Package 18-SOIC
Family Part Number ULN2803A
Manufacturer Pack Quantity 40
MSL Level 2 (1 Year)
Win Source Part Number 1277102-ULN2803ADW
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ULN2803ADW CAD Model

Description

The ULN2803ADW is a versatile and robust integrated circuit designed by Texas Instruments, specifically engineered to drive high-voltage, high-current loads. This integrated circuit is part of the ULN2803A series and is encapsulated in a 18-pin wide-body SOIC package, making it suitable for a wide range of applications including relay drivers, hammer drivers, lamp drivers, display drivers (LED and gas discharge), line drivers, and logic buffers.

The ULN2803ADW incorporates eight NPN Darlington pairs that are capable of handling a continuous collector current of 500 mA for each pair. With an output voltage of 50V, it can effectively drive a variety of inductive and resistive loads. Each Darlington pair shares a common cathode clamp diode for fast inductive load switching, which is essential for applications involving motors, solenoids, and other inductive components.

With its high current capability and built-in suppression diodes, the ULN2803ADW provides a direct interface between low-level logic circuitry and multiple peripheral power loads. The device is compatible with TTL, CMOS, PMOS, and NMOS logic families, making it extremely flexible for interfacing with various control systems.

Key features of the ULN2803ADW include:

  • Eight Darlington transistors with common emitters
  • Output current of 500 mA per channel
  • Output voltage of 50V
  • Integral suppression diodes for inductive loads
  • Outputs can be paralleled for higher current capability
  • Thermal shutdown and output clamp diodes
  • Wide operating temperature range: -20°C to 85°C
  • Compatible with 5V TTL and CMOS logic systems

The ULN2803ADW is an ideal choice for designers looking for a high-power, easy-to-use solution for driving a wide array of loads. Its robustness, combined with Texas Instruments' reputation for high-quality components, ensures reliable performance in demanding applications.

Whether you are designing professional equipment or DIY electronics projects, the ULN2803ADW offers a practical and efficient solution for controlling high-power outputs with logic-level signals.
