Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5.5V (Max)
Minimum Breakdown Voltage 6.5V
Max Clamping Voltage 15V (Typ)
Peak Pulse Current(Ippm) 3A (8/20μs)
Power Dissipation - Pd 45W
Power Line Protection Yes
Applications Ethernet, HDMI
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 114133-TPD4E1U06DBVR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TPD4E1U06
Introduction Date December 19, 2012
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPD4E1U06DBVR CAD Model

Description

TPD4E1U06DBVR from Texas Instruments is a TVS diode device commonly used to help protect sensitive signal lines from electrostatic discharge and related transient events in compact electronic designs. Engineers typically consider parts in this category for portable devices, consumer interfaces, industrial control boards, communication ports, and embedded systems where exposed I/O lines can be vulnerable to ESD. Its value is in supporting system-level robustness while helping preserve board space in dense layouts. For procurement and design teams, this component is best positioned as a protection solution for circuits that need practical transient suppression from a widely recognized semiconductor supplier. The current lifecycle status provided here is Unknown, so teams should confirm ongoing production status directly with Texas Instruments or authorized channel sources before locking it into new designs. RoHS compliance information is not available in the provided data, and engineers should verify the latest environmental compliance details through official manufacturer documentation before approval or shipment.
