The TDA8359J is a high-performance integrated circuit produced by NXP Semiconductors, specifically designed for use in color television sets. This IC is part of NXP's broad portfolio of solutions tailored for the consumer electronics market, with a focus on combining innovation and reliability.

Key Features

• Integrated E/W Amplifier: The TDA8359J includes an East/West (E/W) correction amplifier, which is essential for correcting the geometry of the displayed image on CRT screens, ensuring that viewers enjoy a perfectly proportioned picture.
• DC Coupling Capability: This IC allows for direct coupling to the deflection yoke, which means that no capacitors are needed, thus simplifying the circuit design and reducing the overall bill of materials.
• Vertical Guardband: The vertical guardband feature in the TDA8359J ensures that the vertical deflection is shut down in a controlled manner, protecting the internal components from potential damage due to abrupt changes.
• Flexible Supply Voltage: The device operates efficiently across a range of supply voltages, accommodating the varying power requirements of different television designs.

Applications

The TDA8359J is primarily used in the deflection systems of color televisions. Its robust design makes it suitable for a variety of television sizes and types, including portable units, standard CRT TVs, and large-screen televisions. It is also an excellent choice for high-end monitors that require precise image geometry control.

Quality and Support

NXP is known for its commitment to quality, and the TDA8359J is no exception. It is manufactured under stringent conditions to ensure high reliability and performance over an extended operational lifespan. Additionally, NXP provides comprehensive technical support for the TDA8359J, including detailed datasheets, application notes, and design-in support to assist manufacturers in integrating this IC into their products with ease.

Environmental Considerations

Consistent with NXP's dedication to environmental stewardship, the TDA8359J is produced with eco-friendly materials and processes, complying with international regulations such as RoHS. This commitment ensures that the product is not only advanced in terms of technology but also responsible in its environmental impact.
