Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Maxim Integrated
Series VariableSpeed/BiLevel
Packaging Tube
Type Hot Swap Controller, Sequencer
Number of Channels 2
Internal Switch(s) No
Applications PCI Express
Features Latched Fault, UVLO
Programmable Features Circuit Breaker, Current Limit, Fault Timeout
Operating Supply Voltage 1 V ~ 13.2 V
Operating Temperature Range 0°C ~ 85°C
Operating Supply Current 1.2mA
Mounting SMD
Package 16-SSOP (0.154", 3.90mm Width)
Manufacturer Package 16-QSOP
Feature Pins INC+, LIM1, LIM2, MON1, MON2, ON, OUTC, PGOOD, TIM
Win Source Part Number 786589-MAX5909UEE+
Popularity Medium
Supply and Demand Status Balance
Family Name MAX5909
Introduction Date October 01, 2001
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MAX5909UEE+ CAD Model

Description

Maxim Integrated MAX5909UEE+ Product Overview

The MAX5909UEE+ is a high-performance, dual hot-swap controller designed by Maxim Integrated to ensure safe insertion and removal of circuit boards from live backplanes. This device is ideal for protecting systems that require hot-plugging capability to maintain uninterrupted operation and serviceability. It is commonly used in applications such as servers, RAID systems, telecom equipment, and network routers.

Key Features and Benefits

  • Integrated Dual Channel: The MAX5909UEE+ features two independent hot-swap controllers, allowing for the management of two separate power rails simultaneously.
  • Adjustable Overcurrent Protection: Users can set precise overcurrent protection thresholds through external resistors, ensuring tailored protection for specific circuit requirements.
  • Programmable Startup Time: The startup time is programmable, which helps in managing inrush current and reducing system stress during power-up.
  • Under-Voltage Lockout (UVLO): The UVLO feature prevents the system from operating at dangerously low voltages, which could otherwise lead to malfunction or damage.
  • Circuit Breaker Function: This device incorporates a circuit breaker function that latches off after a fault condition, providing robust protection against prolonged overcurrent events.
  • High Accuracy: The MAX5909UEE+ offers high accuracy current sensing, which is critical for reliable system protection and performance monitoring.
  • Status Reporting: It includes status outputs for signaling to the main controller when a fault condition occurs, enabling timely intervention and system management.

Package and Operating Conditions

The MAX5909UEE+ is offered in a compact 16-pin QSOP package, which is suitable for space-constrained applications. The device operates over a wide temperature range of -40°C to +85°C, ensuring reliable performance in various environmental conditions.

Applications

With its versatile feature set and robust design, the MAX5909UEE+ is an excellent choice for managing hot-swap events in critical systems where uptime and reliability are paramount. Its high level of integration and protection features make it a go-to solution for engineers looking to enhance the safety and durability of their electronic systems.
