Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Type Hot Swap Controller
Number of Channels 1
Applications InfiniBand
Features Auto Retry, OVP
Programmable Features Current Limit, Fault Timeout, Slew Rate
Supply Voltage - Operating 2.3 V to 16.5 V
Temperature Range - Operating -40°C to 85°C
Operating Supply Current 1.6mA
Mounting SMD (SMT)
Case / Package 16-QSOP
Feature Pins CFILTER, COMP+, COMP-, COMPOUT, CPOR, CRWBR, DIS, /FAULT, FB, ON, OV, /POR, PWRGD, REF
Win Source Part Number 023241-MIC2085-JYQS
Ultra Librarian 3D Model Ultra Librarian MIC2085-JYQS CAD Model

Description

The MIC2085-JYQS is a high-performance, single-channel power distribution switch designed by Microchip Technology, a leader in the field of smart, connected, and secure embedded control solutions. This power switch is tailored to provide a reliable and efficient solution for USB and other hot-swap applications.

Key Features

  • Integrated Single Channel: The MIC2085-JYQS offers a single channel for power distribution, making it an ideal solution for managing individual power lines in complex systems.
  • Programmable Current Limit: Users can set the current limit to match the needs of their specific application, protecting both the power switch and the downstream devices from overcurrent conditions.
  • Fast Short-Circuit Response: The device is designed to respond quickly to short-circuit conditions, minimizing the risk to connected components.
  • Thermal Shutdown Protection: With built-in thermal shutdown protection, the MIC2085-JYQS prevents overheating, ensuring the longevity and reliability of the power distribution system.
  • Under-Voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off if the input voltage is below a certain threshold, protecting the device and connected peripherals from low-voltage conditions.
  • Reverse Current Blocking: This function prevents current from flowing backward through the switch, safeguarding the input source from potential damage.

Applications

The MIC2085-JYQS is versatile and can be used in a variety of applications, including:

  • USB hubs, peripherals, and powered ports
  • Hot-swap power supplies
  • Portable consumer electronics
  • Industrial and automotive systems

Quality and Reliability

Microchip Technology is known for its commitment to quality, and the MIC2085-JYQS is no exception. It is manufactured to the highest standards to ensure consistent performance and reliability across a wide range of operating conditions.

Support and Resources

For designers and engineers, Microchip Technology provides extensive support and resources, including datasheets, application notes, and design tools, to facilitate the integration of the MIC2085-JYQS into their projects.
