Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Hot Swap Controllers
Mfr Maxim Integrated
Package Bulk
Product Status Active
Type Hot Swap Controller, Sequencer
Number of Channels 2
Internal Switch(s) Both
Applications PCI Express®
Features Fault Timeout, Latched Fault, OVP, UVLO
Programmable Features Circuit Breaker, Current Limit, Fault Timeout, OVP, UVLO
Voltage - Supply 1V ~ 13.2V
Temperature Range - Operating 0°C ~ 85°C (TA)
Current - Supply 1.2 mA
Mounting Type Surface Mount
Package / Case 16-SSOP (0.154", 3.90mm Width)
Supplier Device Package 16-QSOP
Base Product Number MAX5909
Standard Package 53 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.31.0001
Win Source Part Number 631634-MAX5909UEE
Ultra Librarian 3D Model Ultra Librarian MAX5909UEE CAD Model

Description

Maxim Integrated MAX5909UEE Power-Supply Sequencer

The Maxim Integrated MAX5909UEE is a sophisticated power-supply sequencer designed to manage the power-up and power-down sequence of multiple supply voltages in complex electronic systems. This small, efficient device ensures that various system power rails are enabled and disabled in the correct order, thereby protecting sensitive components and extending system reliability.

Key Features

  • Multiple Voltage Monitoring: The MAX5909UEE can monitor up to four supply voltages, making it versatile for systems with multiple power rails.
  • Adjustable Sequencing: Users can program the sequence timing to meet specific system requirements, ensuring compatibility with a wide range of applications.
  • Power-Fail Input: A dedicated power-fail input allows the device to initiate an immediate shutdown sequence, protecting the system from potential damage due to power failure.
  • External Capacitor Programmable Delays: By connecting external capacitors, users can set precise power-up and power-down delays for each voltage rail.
  • Compact Package: The MAX5909UEE comes in a 16-pin QSOP package, saving valuable board space in densely packed electronic systems.

Applications

With its robust feature set, the MAX5909UEE is ideal for a variety of applications, including:

  • Telecommunications equipment
  • Networking hardware
  • Servers and data centers
  • Industrial control systems
  • Complex multi-rail digital systems

Technical Specifications

The MAX5909UEE operates over a wide voltage range and offers the following technical specifications:

  • Supply Voltage Range: 2.7V to 5.5V
  • Operating Temperature Range: -40°C to +85°C
  • Package Type: 16-pin QSOP

Overall, the Maxim Integrated MAX5909UEE power-supply sequencer is a reliable and flexible solution for managing power sequences in sophisticated electronic systems. Its programmable nature and compact form factor make it an excellent choice for designers looking to optimize system performance and longevity.
