744833120060 Wurth Electronics Inc – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

744833120060

Part No 744833120060
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 12MH 6A 3LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 3
Inductance @ Frequency 12 mH @ 10 kHz
Current Rating (Max) 6A
DC Resistance (DCR) (Max) 65mOhm
Voltage Rating - AC 500V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 1.850" Dia (47.00mm)
Height (Max) 1.535" (39.00mm)
Case / Package Horizontal, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1507028-744833120060
Ultra Librarian 3D Model Ultra Librarian 744833120060 CAD Model
