STEVAL-IHM006V1 - STMicroelectronics Evaluation Board

The STEVAL-IHM006V1 from STMicroelectronics is a sophisticated evaluation board designed for the rapid development and testing of motor control applications. Specifically created to work with a wide range of motor types, this versatile board is an ideal starting point for engineers and developers looking to explore the capabilities of STMicroelectronics' advanced motor control solutions.

This evaluation board is built around the STM32F103CB microcontroller, which delivers the performance required for complex motor control algorithms. The microcontroller is part of the STM32F1 series, known for its high performance, ARM Cortex-M3 32-bit RISC core, and a wide range of peripherals that are optimized for motor control applications.

The STEVAL-IHM006V1 is equipped with a fully integrated three-phase inverter bridge based on the STGIPN3H60 SLLIMM™ (Small Low-Loss Intelligent Molded Module) IPM (Intelligent Power Module). This module is designed to drive three-phase motors in applications that demand high efficiency, compactness, and reliability. The IPM includes short-circuit rugged IGBTs and an assortment of protection features, ensuring the longevity and safety of your motor control projects.

In addition to the hardware features, the evaluation board comes with a comprehensive set of firmware libraries that are compatible with the STM32Cube software development platform. These libraries provide a rich set of motor control algorithms, including Field Oriented Control (FOC), six-step control, and sensorless vector control, which can be used to reduce time-to-market for a wide range of motor control applications.

Other notable features of the STEVAL-IHM006V1 include:

• On-board debugger/programmer with SWD connector
• Overcurrent and overvoltage protection
• Undervoltage lockout
• Three-phase hall sensor interface
• Potentiometer available for speed control
• User LEDs and buttons for interactive control and feedback

The STEVAL-IHM006V1 evaluation board is an excellent tool for engineers looking to develop advanced motor control systems with reduced development time and increased reliability. Whether for industrial applications, consumer products, or innovative new designs, this board offers a powerful platform to bring your motor control solutions to life.
