Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr ON Semiconductor
Package Tape & Reel
Product Status Obsolete
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 40 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 550 mV @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 40 V
Mounting Type Surface Mount
Package / Case DO-216AA
Supplier Device Package Powermite
Base Product Number MBRM140
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 633771-MBRM140T1
Ultra Librarian 3D Model Ultra Librarian MBRM140T1 CAD Model

Description

The MBRM140T1 is a Schottky Barrier Rectifier designed and manufactured by ON Semiconductor, a leader in energy-efficient innovations. This component is engineered to offer low forward voltage drop while providing superior switching performance and high surge capability. It's an ideal choice for high-efficiency power management applications.

Key Features

  • Low Forward Voltage Drop: The device boasts a low forward voltage drop, which enhances system efficiency and reduces thermal issues, making it suitable for high-frequency applications.
  • High Surge Capacity: With its robust surge handling capability, the MBRM140T1 can withstand transient over-voltage conditions, ensuring reliability and longevity in harsh environments.
  • Power Surface Mount Package: The compact surface-mount package allows for a streamlined PCB design and is compatible with automated assembly processes, saving space and reducing manufacturing costs.
  • Guard Ring Die Construction: The inclusion of a guard ring significantly enhances the device's reliability by providing protection against voltage spikes and enhancing its ruggedness.

Electrical Characteristics

  • Peak Repetitive Reverse Voltage (Vrrm): 40V
  • Average Rectified Forward Current (Io): 1.0A
  • Maximum Forward Voltage Drop (Vf): 0.385V at 1.0A
  • Maximum DC Reverse Current (Ir): 2.0mA at 25°C

Applications

The MBRM140T1 is versatile and can be used in a variety of applications, including:

  • Power supply management
  • DC-DC converters
  • Free-wheeling diodes
  • Reverse battery protection
  • Automotive applications
  • Portable devices and battery-powered gadgets

Environmental and Regulatory Compliance

ON Semiconductor is committed to environmental stewardship. The MBRM140T1 is compliant with RoHS (Restriction of Hazardous Substances) and is designed to meet various international environmental regulations, ensuring that it is suitable for use in a wide range of markets and applications.
