Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
RF Type Cellular, GSM, PCS, Wireless Modem, TDMA
Frequency 850MHz to 2GHz
Features Dual Output
Case / Package 10-MSOP
Win Source Part Number 127048-LTC1757A-2EMS#PBF
Ultra Librarian 3D Model Ultra Librarian LTC1757A-2EMS#PBF CAD Model

Description

Linear Technology LTC1757A-2EMS#PBF Overview

The LTC1757A-2EMS#PBF is a high-performance, monolithic synchronous step-down switching regulator from Linear Technology, now part of Analog Devices. This compact and efficient power management integrated circuit is designed to deliver continuous output currents up to 2A with excellent line and load regulation.

Key Features

  • High Efficiency: The LTC1757A-2EMS#PBF boasts a high efficiency that can reach up to 95%, minimizing heat generation and making it suitable for energy-sensitive applications.
  • Wide Input Voltage Range: This device can operate with an input voltage range from 2.75V to 9.8V, accommodating a variety of power sources and ensuring versatility in different system designs.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.8V to VIN, allowing for a wide range of output voltages to meet the requirements of various applications.
  • Fixed Frequency Operation: It operates at a fixed frequency of 550kHz, which allows for a predictable noise spectrum and the use of small external components.
  • Stable with Ceramic Capacitors: The LTC1757A-2EMS#PBF can achieve stability with high-value, low-ESR ceramic output capacitors, which reduces the overall size and cost of the power supply design.
  • Internal Soft-Start: The built-in soft-start function reduces inrush current during startup, providing a controlled power-up sequence.
  • Overtemperature Protection: Integrated overtemperature protection ensures the device operates within safe temperature limits, enhancing system reliability.
  • Compact Package: Enclosed in a compact MSOP-10 package, the LTC1757A-2EMS#PBF is ideal for space-constrained applications.

Applications

The LTC1757A-2EMS#PBF is well-suited for a range of applications, including:

  • Portable Instruments
  • Battery-Powered Equipment
  • Wireless and DSL Modems
  • Step-Down Converters for Multiple Rails
  • Point-of-Load Power Supplies

With its high-efficiency performance and flexible design options, the LTC1757A-2EMS#PBF is a reliable choice for designers looking to create compact, power-efficient solutions in their electronic projects.
