Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Push-Pull, Push-Pull
Reset Active High/Active Low
Reset Timeout 140 ms Minimum
Voltage - Threshold 4.65V
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 120143-MAX707CSA+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX707CSA+ CAD Model

Description

Product Overview: MAX707CSA+ from Maxim Integrated

The MAX707CSA+ is a high-quality supervisory circuit manufactured by Maxim Integrated, designed to monitor power supplies in microprocessor systems. It provides a significant layer of protection by ensuring that the system's voltage levels remain within operational thresholds, thus safeguarding the system from damage due to power surges or failures.

Key Features

  • Voltage Monitoring: This device is adept at monitoring its own power supply voltage and asserting a reset if it detects any voltage that falls outside the pre-programmed thresholds.
  • Reset Output: The MAX707CSA+ offers a reset output feature which remains asserted for a minimum of 140ms after the voltage level returns to an acceptable range. This ensures the system has ample time to stabilize before resuming operation.
  • Low Power Consumption: With its low power consumption design, the product is an ideal choice for portable and battery-operated devices, ensuring minimal drain on the power source.
  • Manual Reset Feature: The inclusion of a manual reset input allows for a system reset to be triggered with an external pushbutton or other input, offering additional control to the user.
  • Watchdog Timer: The integrated watchdog timer is a critical feature for systems requiring regular monitoring of software and processor activity, helping to prevent system hangs and crashes.

Applications

The MAX707CSA+ is versatile and can be used in a variety of applications, including:

  • Microprocessor systems
  • Computers and controllers
  • Portable/Battery-powered equipment
  • Embedded systems
  • Industrial controls

Technical Specifications

Encased in an 8-pin SOIC package, the MAX707CSA+ operates over a wide temperature range, making it suitable for diverse environmental conditions. It supports a wide voltage range and has the ability to interface with multiple types of microprocessors.

Conclusion

The MAX707CSA+ from Maxim Integrated is a robust and reliable solution for system supervision. Its comprehensive set of features ensures that your electronic systems operate within their intended parameters, providing both protection and peace of mind.
