Products specifications Report Issue?

Manufacturer Knowles
Category Audio Products
Family Microphones
Win Source Part Number 192380-SPM0103ND3-3
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SPM0103ND3-3 CAD Model

Description

The Knowles SPM0103ND3-3 is a miniature silicon microphone designed for a wide range of audio applications. It distinguishes itself with its small footprint, low power consumption, and excellent signal-to-noise ratio, making it well-suited for integration into compact, battery-operated devices where high-quality audio capture is essential.

Applications:

  • Smartphones: Used for clear voice communication and audio recording functionalities.
  • Tablets: Integrated into tablets for video conferencing, voice commands, and general audio input.
  • Wireless Earbuds: Enables high-quality voice calls and audio recording in compact earbud designs.
  • Smartwatches: Provides voice input capabilities for smartwatches, enabling voice commands and calls.
  • Hearing Aids: Used for sound amplification and processing in hearing aid devices.
  • Digital Recorders: Integrated for high-fidelity audio recording in portable digital recorders.
  • IoT Devices: Incorporated into smart home and industrial IoT devices for voice control and acoustic sensing.

Features:

  • Ultra-Small Size: Miniature dimensions allow for seamless integration into space-constrained devices.
  • Low Power Consumption: Minimizes power draw to extend battery life in portable applications.
  • High Signal-to-Noise Ratio (SNR): Delivers clear and crisp audio with minimal background noise interference.
  • Omnidirectional Polar Pattern: Captures sound equally from all directions for consistent performance.
  • Digital Output: Provides a digital signal, simplifying integration with digital signal processors (DSPs) and microcontrollers.
  • Surface Mount Technology (SMT): Designed for automated and efficient assembly on printed circuit boards.
  • RoHS Compliant: Adheres to environmental regulations, ensuring minimal environmental impact.

Benefits:

  • Superior Audio Quality: High SNR ensures clear and natural-sounding audio recordings and voice communication.
  • Prolonged Battery Life: Low power consumption maximizes the operational time of battery-powered devices.
  • Flexible Design Options: Small size offers greater design freedom and integration possibilities.
  • Enhanced Voice Recognition Accuracy: Clear audio capture improves the performance of voice recognition systems.
  • Proven Reliability: Knowles is a reputable manufacturer known for delivering high-quality and reliable components.
  • Simplified System Design: Digital output streamlines the connection to digital processing units, reducing complexity.
  • Robust Construction: Designed to withstand various environmental conditions and mechanical stresses.

The SPM0103ND3-3 operates on a low supply voltage, typically ranging from 1.6V to 3.6V, and features a sensitivity level around -42 dBV/Pa. Its omnidirectional characteristic makes it suitable for environments where the sound source position is variable. It is designed for reflow soldering, aligning with standard PCB assembly processes. Its digital output stage minimizes the need for external amplification, thereby decreasing the system's component count and cost. The Knowles SPM0103ND3-3 delivers a combination of compact size, low energy consumption, and excellent performance, making it a preferred choice for audio applications demanding a small, efficient, and high-quality microphone.
