Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Intel
Packaging Tape and Reel
Status Obsolete
Type Non-Isolated PoL Module
Voltage - Input (Minimum) 2.375V
Voltage - Input (Maximum) 5.5V
Voltage - Output 1 0.8 ~ 3.3V
Current - Output (Maximum) 3A
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, OVP, UVLO
Temperature Range - Operating 0°C ~ 70°C
Efficiency 90%
Mounting Style SMD
Manufacturer Package 36-PowerDFN Module
Parts Dimension 0.49" L x 0.32" W x 0.08" H (12.5mm x 8.1mm x 2.1mm)
Supplier Device Package 36-DFN (12.5x8.1)
Control Features Enable, Active High
Family Part Number EN5330
Manufacturer Pack Quantity 1,000
MSL Level 3 (168 Hours)
Win Source Part Number 087202-EN5330DC
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian EN5330DC CAD Model

Description

Product Overview

The EN5330DC provides a comprehensive power management solution, combining high efficiency and reduced footprint to cater to sophisticated electronic systems. This compact integrated circuit is designed to support dynamic power needs, whether for consumer electronics or industrial applications.

Key Features and Benefits

  • Multi-functionality: Integrates several power management features into one chip, decreasing the need for external components.
  • High Efficiency Rates: Ensures significant energy savings and heat reduction, essential for mobile and portable devices.
  • Compact and Durable: Engineered to withstand challenging environments while maintaining a small size for space control.

Applications

  • Embedded Systems
  • Power Supplies
  • Medical Equipment

The EN5330DC is the ideal solution for efficient and space-conscious power management in modern electronic systems.
