Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Current Regulation/Management
Mfr Texas Instruments
Series -
Package Tape & Reel
Product Status Active
Function Electronic Fuse
Sensing Method -
Accuracy ±5%
Voltage - Input 4.2V ~ 55V
Current - Output 2.35A
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Supplier Device Package 24-VQFN (5x4)
Base Product Number TPS26600
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1355940-TPS26600RHFT
Ultra Librarian 3D Model Ultra Librarian TPS26600RHFT CAD Model

Description

The TPS26600RHFT from Texas Instruments is a robust, high-voltage industrial eFuse integrated circuit designed for applications requiring a controlled and protected power distribution system. This device is engineered to provide advanced protection and monitoring features that ensure the safety and reliability of industrial and commercial equipment.

Key Features

  • Wide Operating Voltage Range: The TPS26600RHFT operates over a wide input voltage range from 4.5V to 55V, making it suitable for various industrial applications.
  • Adjustable Over-Current Protection: The device offers user-configurable over-current protection to safeguard against excessive current draw that could potentially damage the system.
  • Integrated FET: An internal N-channel MOSFET provides a low on-resistance path, ensuring efficient power delivery while minimizing power loss.
  • Overvoltage and Undervoltage Lockout: Overvoltage and undervoltage lockout features protect the system from voltage transients and ensure stable operation under varying supply conditions.
  • Thermal Shutdown: The eFuse includes a thermal shutdown mechanism that prevents overheating, thus enhancing system safety.
  • Reverse Polarity Protection: The device is capable of withstanding reverse polarity conditions, which is critical for preventing damage due to incorrect power supply connections.

Applications

The TPS26600RHFT is ideal for a wide range of applications that require precise power management and distribution, including:

  • Industrial automation and control systems
  • Telecommunication equipment
  • Enterprise servers and storage systems
  • Power distribution units
  • Automotive applications

Package and Reliability

The TPS26600RHFT is offered in a compact, thermally enhanced 16-pin HTSSOP package, which is suitable for space-constrained applications. It is characterized for operation over the industrial temperature range of -40°C to 125°C, ensuring reliable performance in harsh environments.

Ordering Information

To order or for more information about the TPS26600RHFT, visit the Texas Instruments website or contact an authorized distributor. The device's documentation, including datasheets and application notes, is readily available to assist in the design and integration process.
