Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube
Type Fanout Buffer (Distribution), Translator
Input CML, LVDS, LVPECL
Output CML
Frequency - Max 8GHz
Supply Voltage (V) 2.375V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 16-VFQFN Exposed Pad, 16-MLF
Supplier Device Package 16-MLF (3x3)
Family Part Number SY58011
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1263012-SY58011UMG
Manufacturer Homepage www.micrel.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SY58011UMG CAD Model

Description

The SY58011UMG from Microchip Technology is a state-of-the-art ultra-precision CML logic gate and level translator, designed to meet the needs of high-speed communication and data processing systems. This advanced component is part of Microchip's high-performance portfolio, offering a seamless integration for designers working on cutting-edge applications.

Key Features

  • High-Speed Performance: The SY58011UMG operates at a blazing fast speed, enabling signal processing and data manipulation at rates that keep up with the latest high-speed interfaces and protocols.
  • Differential CML Outputs: With Current Mode Logic (CML) differential outputs, the device ensures reduced electromagnetic interference (EMI) and improved signal integrity, which is crucial for maintaining the fidelity of high-speed signals.
  • Flexible Voltage Operation: The device supports a wide range of supply voltages from 2.5V to 3.3V, providing design flexibility and compatibility with various logic levels and system requirements.
  • Power Efficiency: SY58011UMG has been engineered for low power consumption, making it an ideal choice for power-sensitive applications without compromising on performance.
  • Robust Design: The product is designed to withstand harsh industrial environments, ensuring reliability and longevity even under challenging conditions.

Applications

The SY58011UMG is versatile and can be used across a broad range of applications:

  • High-speed data transmission systems
  • Networking and telecommunications
  • Signal conditioning and level translation
  • Backplane and cable driving
  • SerDes (Serializer/Deserializer) systems

Technical Specifications

For technical enthusiasts and professionals, the SY58011UMG comes packed with impressive specifications:

  • Max Data Rate: Exceeds 12.5 Gbps
  • Propagation Delay: Typically 145ps
  • Input Voltage Range: 150mV to 1.2V
  • Operating Temperature Range: -40°C to +85°C

With its robust design, high-speed capabilities, and power efficiency, the SY58011UMG is an excellent choice for engineers looking to push the boundaries of their digital systems. Microchip Technology's commitment to quality and performance is embodied in this product, ensuring that it meets the rigorous demands of today's high-speed digital environments.
