TLV9001IDCKR

Part No TLV9001IDCKR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC CMOS 1 CIRCUIT SC70-5
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 34 Weeks
Features CMOS Amplifier Circuit Rail-to-Rail SC-70-5
Manufacturer Texas Instruments
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C (TA)
Mounting Surface Mount
Package 5-TSSOP, SC-70-5, SOT-353
Case / Package SC-70-5
Family Name TLV9001
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Other Part Number 296-52282-6-ND, 296-TLV9001IDCKRTR, 296-52282-1, 296-52306-6INACTIVE, 296-52282-2, 296-52282-1-ND, 296-TLV9001IDCKRDKR, 296-52282-2-ND, 296-52282-6, 296-TLV9001IDCKRCT
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 900295-TLV9001IDCKR
Ultra Librarian 3D Model Ultra Librarian TLV9001IDCKR CAD Model

Description

The TLV9001IDCKR from Texas Instruments is a high-precision operational amplifier that delivers exceptional performance for a wide range of applications. This single-channel op-amp comes in a compact SC-70 package, making it an ideal choice for space-constrained applications.

Key Features:

  • Low Power Consumption: The TLV9001IDCKR is designed for energy-efficient operation, which is critical for battery-powered devices. It offers a quiescent current of just 335 µA, ensuring minimal impact on overall power usage.
  • Wide Supply Range: Operating with a supply voltage range of 1.8V to 5.5V, this op-amp provides flexibility in various power environments, making it suitable for both single and dual supply operations.
  • High Gain Bandwidth: With a gain bandwidth product of 1 MHz, the TLV9001IDCKR is capable of handling a wide range of frequencies, making it versatile for multiple applications including filtering and signal conditioning.
  • Rail-to-Rail Output: The rail-to-rail output capability allows the op-amp to swing its output voltage close to the supply rails, maximizing the dynamic range in analog circuits.
  • Low Input Offset Voltage: A low input offset voltage of 1 mV ensures accurate signal amplification, reducing error and improving overall system performance.
  • Robust ESD Protection: The device is equipped with an Electrostatic Discharge (ESD) protection system, which enhances its durability and reliability when handling or in harsh environments.

Applications:

The TLV9001IDCKR is highly versatile, suitable for a variety of applications, including:

  • Portable and battery-powered devices
  • Sensor amplification and signal conditioning
  • Active filters
  • Medical devices
  • Consumer electronics
  • Industrial measurement and control systems

With its superior performance and compact form factor, the TLV9001IDCKR operational amplifier from Texas Instruments is an excellent choice for designers looking to enhance the efficiency and reliability of their electronic systems.
