TSM15N50CZ C0G Real Image
Same model may have multiple batches, images only for reference.

TSM15N50CZ C0G

Part No TSM15N50CZ C0G
Manufacturer Taiwan Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CHANNEL 500V 14A TO220 / N-Channel 500 V 14A (Tc) Through Hole TO-220
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr Taiwan Semiconductor Corporation
Package Tube
Product Status Obsolete
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 500 V
Current - Continuous Drain (Id) @ 25°C 14A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 440mOhm @ 7A, 10V
Vgs(th) (Max) @ Id 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 39 nC @ 10 V
Vgs (Max) ±30V
Input Capacitance (Ciss) (Max) @ Vds 2263 pF @ 25 V
Temperature Range - Operating 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package TO-220
Package / Case TO-220-3
Base Product Number TSM15
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names TSM15N50CZ C0G-ND,TSM15N50CZC0G
Standard Package 2,000
Win Source Part Number 1101440-TSM15N50CZ C0G
Ultra Librarian 3D Model Ultra Librarian TSM15N50CZ C0G CAD Model

Description

The TSM15N50CZ C0G is a N-Channel MOSFET transistor, designed for use in discrete semiconductor products such as transistors, FETs, and MOSFETs.

  • Maximum Drain to Source Voltage: 500 V
  • Continuous Drain Current: 14A @ 25°C
  • Rds On (Max) @ Id, Vgs: 440mOhm @ 7A, 10V
  • Gate Charge (Qg) (Max) @ Vgs: 39 nC @ 10 V
  • Input Capacitance (Ciss) (Max) @ Vds: 2263 pF @ 25 V
  • Package: TO-220-3
  • Mounting Type: through hole
  • Manufacturer: Taiwan Semiconductor Corporation
  • Status: obsolete
