SI9410BDY-T1-E3 Vishay SI9410BDY-T1-E3 Real Image SI9410BDY-T1-E3 label picture SI9410BDY-T1-E3 label picture 2
Same model may have multiple batches, images only for reference.
SI9410BDY-T1-E3 Vishay SI9410BDY-T1-E3 Real Image SI9410BDY-T1-E3 label picture SI9410BDY-T1-E3 label picture 2
SI9410BDY-T1-E3 Vishay SI9410BDY-T1-E3 Real Image SI9410BDY-T1-E3 label picture SI9410BDY-T1-E3 label picture 2
Same model may have multiple batches, images only for reference.

SI9410BDY-T1-E3

Part No SI9410BDY-T1-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 6.2A 8SOIC
Datasheet
SI9410BDY-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 6.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 23nC @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.5W (Ta)
Maximum Rds On at Id,Vgs 24 mOhm @ 8.1A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 028712-SI9410BDY-T1-E3
Family Name Si9410BDY
Introduction Date July 01, 2003
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SI9410BDY-T1-E3 CAD Model

Description

The Vishay 028712-SI9410BDY-T1-E3 is an N-channel MOSFET with a maximum power dissipation of 1.5W (Ta).

  • Family: Si9410BDY family
  • Drive Voltage: 4.5V and 10V for max Rds On and min Rds On
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 6.2A (Ta)
  • Gate-Source Threshold Voltage: 3V @ 250μA
  • Max Gate Charge: 23nC @ 10V
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On @ Id,Vgs: 24 mOhm @ 8.1A, 10V
  • Supply and Demand: balanced.
