ST-2-56 Real Image
Same model may have multiple batches, images only for reference.

ST-2-56

Part No ST-2-56
Manufacturer Signal Transformer
Catalog Power Transformers
Description PWR XFMR LAMINATED 1.1VA TH /
Datasheet
ST-2-56 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Power Transformers
Mfr Signal Transformer
Series ST
Package Bulk
Type Laminated Core
Voltage - Primary 115V
Voltage - Secondary (Full Load) Parallel 28V, Series 56V
Current - Output (Max) Parallel 40mA, Series 20mA
Primary Winding(s) Single
Secondary Winding(s) Dual
Center Tap No
Power - Max 1.1VA
Mounting Type Through Hole
Termination Style PC Pin
Dimension 34.90mm L x 28.60mm W
Height - Seated (Max) 24.60mm
Voltage - Isolation 2500Vrms
Weight 0.17 lb (77.11 g)
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Standard Package 100
Win Source Part Number 1096477-ST-2-56
Ultra Librarian 3D Model Ultra Librarian ST-2-56 CAD Model

Description

The ST-2-56 is a laminated core Power Transformer designed for use in electronic circuits.

  • Termination Style: PC Pin
  • Packaging: bulk
  • Maximum Power: 1.1VA
  • Voltage - Isolation: 2500Vrms
  • Primary Winding Voltage - Nom: 115V
  • Secondary Winding Voltage - Full Load: 28V (Parallel), 56V (Series)
  • Weight: 0.17 lb (77.11 g)
  • Mounting Type: through hole
  • Alternative Part: ST-2-56ST2-56
