Same model may have multiple batches, images only for reference.
712A Real Image
Same model may have multiple batches, images only for reference.

712A

Part No 712A
Manufacturer Hammond Manufacturing
Catalog Power Transformers
Description PWR XFMR LAMINATED 130VA CHAS MT
Datasheet
712A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Power Transformers
Manufacturer Hammond Manufacturing
Packaging Bulk
Type Laminated Core
Voltage - Primary 117V, 234V
Voltage - Secondary (Full Load) 850V
Current - Output (Max) 215mA
Primary Winding(s) Single
Secondary Winding(s) Single
Center Tap Yes
Power - Max 130VA
Mounting Chassis Mount
Termination Style Wire Leads
Size / Dimension 117.60mm L x 95.25mm W
Height - Seated (Max) 114.30mm
Weight 8.8 lbs (4 kg)
RoHS Status ROHS3 Compliant
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4065
Other Part Number 712AHM,712AHM-ND,HM5162
Standard Package 1
Win Source Part Number 1334222-712A
Ultra Librarian 3D Model Ultra Librarian 712A CAD Model

Description

The 1334222-712A is a power transformer electronic component manufactured by Hammond Manufacturing.

  • Transformer Type: laminated core
  • Termination: wire leads
  • Size: 117.60mm L x 95.25mm W
  • Seated Height: 114.30mm
  • Maximum Power: 130VA
  • Weight: 8.8 lbs (4 kg)
  • Primary Winding: single
  • Secondary Winding: single, with center tap
  • Maximum Current Output: 215mA
  • Voltage @ Full Load: 850V
  • Packaging: bulk
  • Mounting Type: chassis
