MPEN-230AF Sanken
Same model may have multiple batches, images only for reference.

MPEN-230AF

Part No MPEN-230AF
Manufacturer Sanken
Catalog Diodes, Rectifiers - Arrays
Description SCHOTTKY BARRIER DIODE (SURFACE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Sanken
Package Bulk
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 900 mV @ 15 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 250 µA @ 100 V
Operating Temperature - Junction -40°C ~ 150°C
Mounting Type Through Hole
Package / Case TO-262-3 Long Leads, I²Pak, TO-262AA
Supplier Device Package TO-262
Base Product Number MPEN-230
Standard Package 1,000 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 239826-MPEN-230AF
Ultra Librarian 3D Model Ultra Librarian MPEN-230AF CAD Model

Description

The 239826-MPEN-230AF is a diode rectifier array designed for fast recovery applications.

  • Maximum Reverse Voltage Rating: 100V
  • Forward Voltage: 900mV @ 15A
  • Diode Configuration: Common Cathode Pair
  • Average Rectified Current: 30A per diode
  • Mounting: Through Hole
  • Package: TO-262-3 long leads
  • Operating Temperature: -40°C to 150°C
  • Status: Active
  • Manufacturer: Sanken

It is commonly used in high-power rectifier circuits and is known for its excellent performance and reliability.
