Same model may have multiple batches, images only for reference.
83CNQ100ASM Real Image
Same model may have multiple batches, images only for reference.

83CNQ100ASM

Part No 83CNQ100ASM
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description SCHOTTKY RECTIFIER | DIODE ARRAY SCHOTTKY 100V D618SM
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Bulk
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 100V
Current - Average Rectified (Io) (per Diode) 40A
Voltage - Forward (Vf) (Maximum) at If 1V at 80A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1.5mA at 100V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Style Through Hole
Manufacturer Package D-61-8-SM
Supplier Device Package D-61-8-SM
Family Part Number 83CNQ100
Manufacturer Pack Quantity 400
MSL Level 1 (Unlimited)
Win Source Part Number 1133956-83CNQ100ASM
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 83CNQ100ASM CAD Model

Description

The Vishay Semiconductor Diodes Division produces the 83CNQ100ASM, a Schottky diode with a maximum DC reverse voltage of 100V.

  • Maximum DC Reverse Voltage: 100V
  • Recovery Speed: 200mA
  • Operating Temperature Range: -55°C to 175°C
  • Configuration: Common Cathode
  • Average Rectified Current: 40A per diode
  • Mounting Style: Through-Hole
  • Package: Bulk
  • Status: Obsolete
  • Popularity: Medium
  • Quantity: 400
  • Package: D-61-8-SM
