PS22A76 Mitsubishi PS22A76 Real Image1 PS22A76 Real Image2
Same model may have multiple batches, images only for reference.
PS22A76 Mitsubishi PS22A76 Real Image1 PS22A76 Real Image2
PS22A76 Mitsubishi PS22A76 Real Image1 PS22A76 Real Image2
Same model may have multiple batches, images only for reference.

PS22A76

Part No PS22A76
Manufacturer Powerex Inc.
Catalog Power Drivers - Modules
Description MOD IPM 1200V 25A LARGE DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Power Driver Modules
Mfr Powerex Inc.
Series DIPIPM™
Package Bulk
Product Status Discontinued
Type IGBT
Configuration 3 Phase
Current 25 A
Voltage 1.2 kV
Voltage - Isolation 2500VDC
Mounting Type Through Hole
Package / Case 42-PowerDip Module (1.404", 35.67mm)
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 656757-PS22A76
Ultra Librarian 3D Model Ultra Librarian PS22A76 CAD Model

Description

The 656757-PS22A76 is a 3-phase IGBT power driver module from the DIPIPM™ series.

  • Product: 656757-PS22A76
  • Manufacturer: Powerex Inc.
  • Series: DIPIPM™
  • Type: 3-Phase IGBT Power Driver Module
  • Voltage Rating: 1.2 kV
  • Current Rating: 25 A
  • Voltage Isolation: 2500VDC
  • Mounting Type: Through-hole
  • Package: 42-PowerDip Module
  • Package Quantity: 1 Piece
  • Category: Discrete Semiconductor Products - Power Driver Modules
  • Status: Discontinued
