The PTN3380BBS is a high-performance DisplayPort to VGA adapter integrated circuit (IC) from NXP Semiconductors. This advanced chip is designed to connect DisplayPort-enabled devices to VGA monitors, projectors, or other display units, providing a seamless and high-quality video experience. The PTN3380BBS is an ideal solution for users looking to bridge the gap between new digital interfaces and legacy analog video outputs.

Key Features

• High-Resolution Support: The PTN3380BBS supports video resolutions up to 1920x1200 at 60 Hz, ensuring clear and sharp images for a variety of multimedia applications.
• Automatic Sink Detection: With its smart sink detection feature, the PTN3380BBS can automatically detect when a VGA display is connected and configure the video output accordingly.
• Low Power Consumption: Designed with power efficiency in mind, the PTN3380BBS operates with low power consumption, making it suitable for battery-powered devices.
• EDID Pass-Through: The device supports Extended Display Identification Data (EDID) pass-through from the VGA display to the DisplayPort source, ensuring optimal compatibility and display performance.
• Plug and Play: As a plug-and-play device, the PTN3380BBS does not require additional drivers or software, offering ease of use and a quick setup process.

Applications

The PTN3380BBS is versatile and can be used in various applications, including:

• Desktop and laptop PCs with DisplayPort outputs
• DisplayPort graphics cards
• Docking stations
• DisplayPort-enabled mobile devices
• Video conferencing systems

Technical Specifications

The PTN3380BBS is built with the following technical specifications:

• Package: HVQFN32
• Operating Temperature: 0°C to 70°C
• Supply Voltage: 3.3V

With its robust feature set and compatibility with both new and old video standards, the PTN3380BBS from NXP Semiconductors is an excellent choice for system designers and consumers looking to maintain connectivity with VGA displays.
