SRF0504-102Y

Part No SRF0504-102Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Description CMC 2.7UH 1.5A 2LN 1KOHM SMD
Datasheet
SRF0504-102Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - Common Mode Chokes
Mfr Bourns Inc.
Series SRF0504
Package Tape & Reel
Product Status Active
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 1 kOhms @ 100 MHz
Inductance @ Frequency 2.7 µH @ 100 kHz
Current Rating (Max) 1.5A
DC Resistance (DCR) (Max) 60mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Size / Dimension 0.205" L x 0.197" W (5.20mm x 5.00mm)
Height (Max) 0.189" (4.80mm)
Package / Case Horizontal, 4 PC Pad
Base Product Number SRF0504
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
California Prop 65 Warning Information
Win Source Part Number 742009-SRF0504-102Y
Ultra Librarian 3D Model Ultra Librarian SRF0504-102Y CAD Model

Description

The SRF0504-102Y is a common mode choke designed for signal line filtering in electronic circuits. It is manufactured by Bourns Inc..

  • Size: 0.205" L x 0.197" W (5.20mm x 5.00mm)
  • Height: 0.189" (4.80mm)
  • Mounting: Surface Mount
  • Voltage Rating: 50V DC
  • Maximum Current Rating: 1.5A
  • Impedance: 1 kOhms @ 100 MHz
  • Inductance: 2.7 µH @ 100 kHz
  • DC Resistance (DCR): 60mOhm
  • Package: Tape & reel with 4 PC pads
  • Temperature Range: -40°C to 125°C
  • Compliance: REACH regulations
  • Series: SRF0504
