The ADM2561EBRNZ-RL7 by Analog Devices Inc. is a robust, high-speed, integrated signal and power isolated transceiver that operates with a single 5 V power supply. It is part of a family of devices that combines industry-leading iCoupler technology with power isolation to offer a complete isolated data communication and power solution.

This transceiver is designed to meet the stringent requirements of industrial data communications with high isolation levels, noise immunity, and reliable performance under harsh operating conditions. The device is suitable for a broad range of applications, including industrial field buses, multipoint data transmission, and other situations where data integrity and isolation are critical.

Key Features:

• Integrated Isolation: The ADM2561EBRNZ-RL7 integrates signal and power isolation in a single package, reducing design complexity and footprint.
• High Data Rates: It supports data rates up to 500 kbps, making it suitable for high-speed data communication.
• High Isolation Voltage: With an isolation voltage of 2.5 kVrms, it provides reliable performance in high-voltage environments.
• Robust Electromagnetic Compatibility (EMC): The device offers excellent EMC performance, including high immunity to electromagnetic interference (EMI).
• Thermal Shutdown Protection: It includes a thermal shutdown feature that protects the device from overheating.

Applications:

• Industrial Automation
• Process Control Systems
• Building Automation
• Networked Sensors and Actuators

The ADM2561EBRNZ-RL7 is available in a compact, surface-mount, 16-lead SOIC wide body package, making it easy to incorporate into various designs. Its combination of features and reliability make it an excellent choice for engineers looking for an isolated transceiver solution that can withstand the rigors of industrial environments.

For more information or to purchase the ADM2561EBRNZ-RL7, visit the Analog Devices Inc. website or contact your local authorized distributor.
