The AD736AQ is a high-precision, low-power True RMS-to-DC converter that delivers a high level of accuracy and versatility. Manufactured by Analog Devices Inc., this integrated circuit is designed to convert complex AC input signals into their true root-mean-square value, which can then be easily measured, displayed, or used for further processing.

Key Features:

• High Accuracy: The AD736AQ offers excellent accuracy over a wide range of input waveforms, including variable duty cycles and crest factors up to 6.
• Low Power Consumption: With its low power design, it is ideal for battery-powered instruments and other portable devices.
• Wide Bandwidth: Capable of measuring signals with frequencies up to 1 MHz, this converter is suitable for a broad range of applications.
• Flexible Power Supply: It operates on a single supply of 5 V to 30 V or dual supplies of ±2.5 V to ±15 V.

Applications:

• Electronic instrumentation
• Energy management systems
• Signal processing
• Industrial controls
• AC power monitoring

Technical Specifications:

The AD736AQ is available in an 8-pin PDIP (Plastic Dual In-line Package), which makes it easy to integrate into a wide variety of systems. With its robust design and reliable performance, this true RMS-to-DC converter is an excellent choice for precision signal processing and measurement in industrial and commercial applications.
