PDB-C154SM Advanced Photonix, Inc.
Same model may have multiple batches, images only for reference.

PDB-C154SM

Part No PDB-C154SM
Manufacturer Advanced Photonix, Inc.
Catalog Optical Sensors - Photodiodes
Description SENSOR PHOTODIODE 660NM 1210
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Optical Sensors - Photodiodes
Mfr Advanced Photonix, Inc.
Package Tape & Reel
Product Status Active
Wavelength 660nm
Color - Enhanced Red
Spectral Range 400nm ~ 1100nm
Diode Type PIN
Response Time 10ns
Voltage - DC Reverse (Vr) (Max) 32 V
Current - Dark (Typ) 2nA
Active Area 2.10mm²
Viewing Angle 120°
Temperature Range - Operating -40°C ~ 80°C
Mounting Type Surface Mount
Package / Case 1210 (3225 Metric)
Base Product Number PDB-C154
Standard Package 3,000 pcs
MSL Level 3 (168 Hours)
ECCN EAR99
HTSUS 8541.49.1050
Win Source Part Number 653875-PDB-C154SM
Ultra Librarian 3D Model Ultra Librarian PDB-C154SM CAD Model

Description

The 653875-PDB-C154SM is a photodiode sensor that falls under the category of Optical Sensors.

  • Response Time: 10ns
  • Maximum Reverse Voltage: 32 V
  • Viewing Angle: 120 degrees
  • Wavelength: 660nm
  • Color Enhancement: Red
  • Spectral Range: 400nm to 1100nm
  • Manufacturer: Advanced Photonix
