V40150C-E3/4W Vishay V40150C-E3/4W Real Image
Same model may have multiple batches, images only for reference.
V40150C-E3/4W Vishay V40150C-E3/4W Real Image
V40150C-E3/4W Vishay V40150C-E3/4W Real Image
Same model may have multiple batches, images only for reference.

V40150C-E3/4W

Part No V40150C-E3/4W
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 150V TO220
Datasheet
V40150C-E3/4W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 150V
Current - Average Rectified (Io) (per Diode) 20A
Voltage - Forward (Vf) (Max) @ If 1.43V @ 20A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 250μA @ 150V
Operating Temperature - Junction -55°C to 150°C
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 1116876-V40150C-E3/4W
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian V40150C-E3/4W CAD Model

Description

The Vishay V40150C-E3/4W is a Schottky diode with a voltage - DC reverse (Vr) (Max) of 150V and a voltage - forward (Vf) (Max) @ If of 1.43V @ 20A.

  • Manufacturer: Vishay
  • Voltage - DC Reverse (Vr) (Max): 150V
  • Voltage - Forward (Vf) (Max) @ If: 1.43V @ 20A
  • Current - Reverse Leakage @ Vr: 250μA @ 150V
  • Operating Temperature - Junction: -55°C to 150°C
  • Mounting: Through-Hole
  • Maximum Current Collector: 20A
  • Status: Active
  • Case/Package: TO-220AB
  • Popularity: Medium
  • Supply and Demand Status: Balanced
  • Category: Discrete Semiconductor Products
  • Diode Configuration: 1 Pair Common Cathode
  • Speed (Frequency): Fast Recovery = 200mA (Io)
