Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Siliconix
Packaging Tube
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 100V
Id - Continuous Drain Current 4.3A
Drive Voltage (Max Rds On, Min Rds On) 4V, 5V
Rds On (Maximum) at Id, Vgs 540mOhm at 2.6A, 5V
Gate Source Voltage(th) (Maximum) at Id 2V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 6.1nC at 5V
Gate Source Voltage (Maximum) ±10V
Input Capacitance (Ciss) (Maximum) at Vds 250pF at 25V
Power Dissipation (Maximum) 2.5W, 25W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package D-Pak
Manufacturer Package TO-252-3, DPak (2 Leads + Tab), SC-63
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1188609-IRLR110
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRLR110 CAD Model

Description

The Vishay Siliconix IRLR110 is an N-channel MOSFET transistor with a drain-source breakdown voltage of 100V and a continuous drain current of 4.3A.

  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 4.3A
  • Maximum Rds On: 540mOhm @ 2.6A, 5V
  • Gate source voltage(th) (maximum) @ Id: 2V @ 250μA
  • Gate charge (Qg) (maximum) @ Vgs: 6.1nC @ 5V
  • Gate source voltage (maximum): ±10V
  • Input capacitance (Ciss) (maximum) @ Vds: 250pF @ 25V
  • Product: discrete semiconductor product
  • Popularity: medium
  • Win Source Part Number: 1188609-IRLR110
  • Supplier Device Package: D-Pak
  • Packaging: tube
  • Mounting Style: SMD
  • Technology: MOSFET
  • FET Feature: -
  • Transistor Polarity: N-Channel
  • Temperature Range - Operating: -55°C ~ 150°C
  • Manufacturer Homepage: www.irf.com
  • Manufacturer Package: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Power Dissipation (maximum): 2.5W, 25W
  • Supply and demand status: balanced
  • Manufacturer Pack Quantity: 50
  • MSL Level: 1 (Unlimited)
