The UCC5642MWPTRG4 is a high-performance SCSI (Small Computer System Interface) terminator manufactured by Texas Instruments, designed to support the Ultra2 LVD (Low Voltage Differential) SCSI interface. This device is specifically tailored to ensure data integrity and maximize performance in SCSI bus systems, which are commonly used in servers, workstations, and storage arrays.

Key Features

• Compatibility: The UCC5642MWPTRG4 is compatible with the SPI-2 (SCSI Parallel Interface-2) standard, ensuring seamless integration with existing Ultra2 LVD SCSI systems.
• Multi-mode Support: It supports LVD, SE (Single-Ended), and HVD (High Voltage Differential) modes, providing versatility and the ability to operate in various SCSI configurations.
• Automatic Termination: This device includes an auto-termination feature that detects the presence of active SCSI devices and adjusts termination accordingly, enhancing ease of use and system reliability.
• Hot-Plugging: The UCC5642MWPTRG4 is designed to support hot-plugging, allowing devices to be added or removed from the SCSI bus without the need to power down the system.
• Power Efficiency: With its low power consumption, the terminator minimizes power draw on the system, which is crucial in environments where energy efficiency is a priority.

Applications

The UCC5642MWPTRG4 is ideally suited for a wide range of applications that require robust and reliable data transmission. Its use cases include:

• Enterprise server SCSI buses
• High-performance workstations
• RAID systems
• Storage area networks (SAN)
• Network attached storage (NAS) devices

Quality and Reliability

Texas Instruments is renowned for its commitment to quality, and the UCC5642MWPTRG4 is no exception. Manufactured with precision and designed for durability, this SCSI terminator is built to withstand the rigors of high-demand systems, ensuring a long operational lifespan and consistent performance.

Ordering Information

The UCC5642MWPTRG4 is available in a 28-pin HTSSOP (Thin Shrink Small Outline Package) and is RoHS compliant. For ordering, availability, and detailed specifications, visit the Texas Instruments website or contact an authorized distributor.
