The TS3USB3200RSVR is a high-performance, integrated USB switch designed by Texas Instruments to cater to the needs of modern electronic devices requiring USB 2.0 switching capabilities. This switch is optimized for applications that demand low on-capacitance (C_on) and low on-resistance (R_on) to minimize signal distortion and attenuation in USB signal paths.

Key Features

• USB 2.0 Compatibility: Fully compliant with the USB 2.0 standard, ensuring seamless integration with existing USB systems and devices.
• Low On-Capacitance and Resistance: The device features a C_on of 3 pF (typical) and an R_on of 6 Ω (typical), which are critical for maintaining signal integrity.
• High Bandwidth: With a bandwidth greater than 720 MHz, this switch is capable of handling high-speed data without compromising performance.
• ESD Protection: Integrated electrostatic discharge (ESD) protection circuitry guards against damage from static electricity, providing a human body model (HBM) ESD rating of ±8 kV.
• Space-Saving Design: Housed in a compact UQFN-10 package, the TS3USB3200RSVR is ideal for space-constrained applications.

Applications

The versatility of the TS3USB3200RSVR makes it suitable for a broad range of applications, including:

• Cell phones and smartphones
• Tablets, notebooks, and ultrabooks
• Desktop computers
• USB peripheral devices
• USB docking stations
• USB hub devices

Additional Information

For designers and engineers looking to integrate the TS3USB3200RSVR into their systems, Texas Instruments provides comprehensive technical documentation, including datasheets, application notes, and design resources. This extensive support ensures that incorporating the TS3USB3200RSVR into your design is as straightforward as possible, enabling rapid development and deployment of USB-enabled devices.

With its robust feature set and Texas Instruments' renowned reliability, the TS3USB3200RSVR stands out as an exceptional choice for designers needing a high-quality USB switch solution.
