Product Overview: TS3USB30EDGSR by Texas Instruments

The TS3USB30EDGSR is a cutting-edge USB 2.0 High-Speed (480 Mbps) switch from Texas Instruments, designed to facilitate the routing of high-speed differential signals. Encased in a compact 10-VSSOP package, this integrated circuit is engineered to switch between two USB sources or destinations, making it an essential component for a wide range of electronic products that require USB connectivity.

Key Features

• High-Speed Performance: The TS3USB30EDGSR is designed to support the USB 2.0 High-Speed standard, ensuring swift and reliable data transfer rates of up to 480 Mbps.
• Low On-Capacitance (C_ON): With a low on-capacitance of 6 pF (typical), the switch minimizes signal attenuation, thereby preserving signal integrity during the switching process.
• Low On-Resistance (R_ON): The device features a low on-resistance of typically 4.5 Ω, which reduces voltage drop and power consumption, enhancing overall system efficiency.
• 1.8-V Compatible Control-Pin Inputs: This feature allows for direct interfacing with low-voltage processors and microcontrollers, thereby simplifying system design and reducing the need for level shifters.
• ESD Protection: The TS3USB30EDGSR is equipped with robust Electrostatic Discharge (ESD) protection circuitry, safeguarding the device against static damage and enhancing its durability.

Applications

The versatility of the TS3USB30EDGSR makes it suitable for a broad array of applications. It is commonly utilized in:

• Cell phones and smartphones
• Tablets and portable media players
• USB hubs, docks, and peripherals
• Notebooks, desktop computers, and servers
• Networking and telecommunication equipment

Quality and Reliability

As with all Texas Instruments products, the TS3USB30EDGSR is manufactured to the highest quality standards, ensuring reliable performance in even the most demanding environments. The device's operational temperature range from -40°C to 85°C guarantees stability across various conditions, making it an excellent choice for industrial and commercial applications.

Whether you are designing a new USB-based device or upgrading an existing system, the TS3USB30EDGSR offers the performance, efficiency, and reliability required to deliver a superior user experience.
