Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Applications USB
Switch Circuit DPDT
Number of Channels 1
Max On Resistance 9 Ohm
Single Supply Voltage (V+) 2.7 V to 4.3 V
-3db Bandwidth 6.1GHz
Features Bi-Directional, USB 2.0
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 10-UQFN (2.0x1.5)
Win Source Part Number 035094-TS3USB3000MRSER
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TS3USB3000
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TS3USB3000MRSER CAD Model

Description

Introducing the TS3USB3000 USB Switch from Texas Instruments

The TS3USB3000 USB Switch is a versatile and high-performance integrated circuit designed by the renowned Texas Instruments. This product is specifically engineered to facilitate the switching of high-speed USB 2.0 signals in handheld and portable consumer applications. With its exceptional design, the TS3USB3000 ensures that users experience reliable and efficient signal switching, making it an indispensable component in modern electronic devices.

Key Features

  • High-Speed Performance: The TS3USB3000 supports USB 2.0 high-speed data rates of up to 480 Mbps, ensuring that devices can transfer data quickly and efficiently.
  • Low Power Consumption: Designed with power efficiency in mind, the TS3USB3000 operates with minimal power consumption, making it ideal for battery-powered devices.
  • Versatility: This USB switch is capable of multiplexing differential signals from a variety of sources, including USB 2.0, UART, PCM, and other low-voltage differential signals.
  • Enhanced Signal Integrity: With built-in ESD protection and minimal signal distortion, the TS3USB3000 ensures the integrity of data transmission is maintained.
  • Compact Design: The small form factor of the TS3USB3000 allows it to be easily integrated into space-constrained applications without compromising performance.

Applications

The TS3USB3000 is highly suitable for a range of applications, including:

  • Smartphones and Tablets
  • Portable Media Players
  • GPS Devices
  • Digital Cameras
  • Other USB Peripheral Devices

Technical Specifications

The TS3USB3000 operates over a wide supply voltage range of 2.3 V to 4.3 V and is available in a compact 10-pin QFN package. It is characterized for operation from -40°C to 85°C, accommodating a broad spectrum of environmental conditions.

For designers and engineers looking for a reliable USB switching solution, the TS3USB3000 from Texas Instruments offers a perfect blend of performance, power efficiency, and versatility. Its robust design and ease of integration make it an excellent choice for enhancing the connectivity of next-generation consumer electronics.

For more information and detailed technical specifications, please refer to the TS3USB3000 datasheet provided by Texas Instruments.
