Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Display Type LED
Configuration 7 Segment + DP
Digits or Characters 8 Digits
Operating Supply Current 330mA
Supply Voltage - Operating 4 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting Through Hole
Case / Package 24-PDIP
Win Source Part Number 003207-MAX7219CNG+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX7219
Introduction Date July 01, 1997
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MAX7219CNG+ CAD Model

Description

The MAX7219CNG+ from Maxim Integrated is a compact, serial input/output common-cathode display driver that can interface microprocessors to a 7-segment numeric LED display of up to 8 digits, bar-graph displays, or 64 individual LEDs. It is included in a 24-pin DIP package, making it suitable for breadboard prototyping and permanent projects alike.

Key Features

  • Integrated Multiplexing: The device integrates BCD code-B decoders, multiplex scan circuitry, segment and digit drivers, and an 8x8 static RAM to store each digit.
  • Individual LED Control: Users can address each LED individually, giving them the freedom to create custom displays or lighting effects.
  • Simplified Wiring: Only one external resistor is needed to set the segment current for all LEDs, which simplifies the hardware design and reduces component count.
  • Digital Interface: The MAX7219CNG+ uses a simple serial interface to communicate with microcontrollers, which can minimize the number of pins required for display control.
  • Daisy Chain Capability: Multiple MAX7219CNG+ devices can be connected in series to control extended displays with a minimal number of interface pins.
  • Low Power Consumption: The device includes a power-saving shutdown mode, which reduces power consumption to less than 10µA.

Applications

The MAX7219CNG+ is versatile and can be used in a variety of applications, including:

  • Point of Sale (POS) Displays
  • Bar Graph Displays
  • Industrial Controllers
  • Panel Meters
  • Digital Clocks

Technical Specifications

Parameter Value Supply Voltage (V<sub>CC) 4.0V to 5.5V Operating Temperature -40°C to +85°C Package Type 24-Pin DIP

Whether you're developing a prototype or a final product, the MAX7219CNG+ offers a reliable and efficient solution for driving LED displays with ease.
