The TPS65150RGER is a high-performance power management integrated circuit (PMIC) designed and manufactured by the renowned Texas Instruments. This advanced chip offers a comprehensive solution for powering small to medium-sized liquid crystal displays (LCDs) that require positive and negative supply voltages.

Key Features

• Dual Output Voltage: The TPS65150RGER provides both positive and negative output voltages from a single input. This feature simplifies the power supply design for LCD panels that need bipolar voltages for optimal operation.
• Adjustable Outputs: With external resistors, users can adjust the output voltages to meet specific requirements, offering great flexibility for various LCD specifications.
• High Efficiency: The device integrates a boost converter with a 2.2-MHz fixed-frequency operation to minimize the size of the external components and ensure efficient power conversion.
• Thermal Protection: It includes thermal shutdown protection to safeguard the device against excessive temperature conditions, enhancing the reliability of the end application.

Applications

The TPS65150RGER is ideally suited for powering a wide range of LCD displays used in automotive, industrial, and consumer electronics applications. Its versatility and efficiency make it a preferred choice for designers looking to optimize their power supply solutions.

Technical Specifications

Ordering Information

The TPS65150RGER is available in a compact, 24-pin VQFN package and can be ordered using the Texas Instruments part number TPS65150RGER. For detailed ordering and shipping information, please consult the Texas Instruments website or contact an authorized distributor.
