Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel
Type Window
Output Type Open Drain
Supply Voltage , Single/Dual (±) 1.8V ~ 18V
Current - Quiescent (Maximum) 11μA
Propagation Delay (Maximum) 29μs
Hysteresis 5.5mV
Temperature Range - Operating -40°C ~ 125°C
Manufacturer Package SOT-23-6 Thin, TSOT-23-6
Mounting Style SMD
Supplier Device Package TSOT-23-6
Family Part Number TPS3700
Manufacturer Pack Quantity 1
MSL Level 2 (1 Year)
Win Source Part Number 1272371-TPS3700DDCT
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TPS3700DDCT CAD Model

Description

Overview of Texas Instruments TPS3700DDCT

The TPS3700DDCT is a high-precision window voltage detector designed by Texas Instruments, renowned for their expertise in semiconductor technology. This advanced integrated circuit (IC) is engineered to monitor over- and undervoltage conditions, ensuring that electronic systems such as microprocessors, power supplies, and battery management systems operate within their safe voltage limits.

Key Features

  • Wide Supply Range: The TPS3700DDCT operates over a broad supply voltage range of 1.8 V to 18 V, making it versatile for a variety of applications.
  • Dual Window Comparator: This IC integrates two independent voltage detectors, enabling it to monitor both overvoltage and undervoltage thresholds with high accuracy.
  • Adjustable Thresholds: The voltage thresholds can be set with external resistive dividers, providing flexibility to set precise voltage monitoring levels specific to the needs of the application.
  • Low Quiescent Current: It features a low quiescent current, which is ideal for battery-powered and energy-efficient applications.
  • Push-Pull/Open-Drain Outputs: The TPS3700DDCT offers both push-pull and open-drain output configurations, allowing for direct interfacing with microcontrollers or other digital systems without the need for additional components.
  • Temperature Range: The device is operational over a wide temperature range, ensuring reliable performance under varying environmental conditions.

Applications

The TPS3700DDCT is suitable for a multitude of applications, including:

  • Power supply monitoring
  • Battery management systems
  • Microprocessor and microcontroller systems
  • Portable and handheld devices
  • Industrial equipment
  • Automotive electronics

Package and Quality

Encased in a small, 8-pin SOT-23 package, the TPS3700DDCT is designed for space-constrained applications. Texas Instruments' commitment to quality ensures that this product meets high standards of performance and reliability, making it a trusted choice for critical system monitoring solutions.
