Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Series PurePath HD
Packaging Reel - TR
Type Class D
Output Type 1-Channel (Mono) or 2-Channel (Stereo)
Max Output Power x Channels @ Load 600W x 1 @ 2 Ohm; 300W x 2 @ 4 Ohm
Operating Supply Voltage 25 V ~ 52.5 V
Features Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown
Mounting SMD
Operating Temperature Range 0°C ~ 70°C (TA)
Manufacturer Package 44-HSSOP
Package 44-BSSOP (0.433", 11.00mm Width) Exposed Pad
Win Source Part Number 1264126-TAS5630DKDR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TAS5630
Introduction Date May 01, 2009
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TAS5630DKDR CAD Model

Description

Introducing the TAS5630DKDR from Texas Instruments

The TAS5630DKDR is a state-of-the-art, high-performance audio amplifier integrated circuit (IC) brought to you by Texas Instruments (TI), a leader in semiconductor solutions. Designed to deliver exceptional sound quality with high efficiency, the TAS5630DKDR is a perfect choice for audio enthusiasts and professionals seeking to build powerful audio systems with compact footprints.

At the heart of the TAS5630DKDR lies TI's advanced closed-loop architecture, which ensures minimal distortion and noise, providing a pristine audio experience. This IC is capable of driving stereo speakers at up to 300 Watts each or a single speaker in a mono bridge-tied load (BTL) configuration at an impressive 600 Watts, making it suitable for a wide range of applications, from home theater systems to professional audio setups.

The TAS5630DKDR supports a wide power supply range from 20V to 50V, giving designers the flexibility to use it in various system designs without the need for multiple power supply voltages. Its high efficiency of over 90% means that not only does it reduce energy consumption, but it also minimizes the need for heat dissipation, allowing for smaller heat sinks and more compact overall designs.

Equipped with multiple protection features, including overcurrent, overvoltage, undervoltage, and thermal protection, the TAS5630DKDR ensures reliable operation under a variety of conditions. These safeguards help to extend the lifespan of the product and maintain consistent performance over time.

For ease of integration, the TAS5630DKDR comes in a 44-pin HTSSOP (D) package, which is optimized for space-saving on printed circuit boards (PCBs). Its pin configuration and package design are intended to simplify the layout process, reducing the time and cost of development.

Whether you're designing a high-fidelity home audio system, a professional-grade stage amplifier, or an advanced automotive audio solution, the TAS5630DKDR from Texas Instruments offers the power, efficiency, and quality you need to deliver outstanding audio performance.
