SN74AHC123APWR Real Image SN74AHC123APWR real image5855 SN74AHC123APWR Real Image1 SN74AHC123APWR Real Image2 SN74AHC123APWR Real Image3 SN74AHC123APWR Real Image4
Same model may have multiple batches, images only for reference.
SN74AHC123APWR Real Image SN74AHC123APWR real image5855 SN74AHC123APWR Real Image1 SN74AHC123APWR Real Image2 SN74AHC123APWR Real Image3 SN74AHC123APWR Real Image4
SN74AHC123APWR Real Image SN74AHC123APWR real image5855 SN74AHC123APWR Real Image1 SN74AHC123APWR Real Image2 SN74AHC123APWR Real Image3 SN74AHC123APWR Real Image4
Same model may have multiple batches, images only for reference.

SN74AHC123APWR

Part No SN74AHC123APWR
Manufacturer Texas Instruments
Catalog Logic - Multivibrators
Description IC DUAL RETRIG MULTIVIB 16-TSSOP
Datasheet
SN74AHC123APWR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Monostable
Independent Circuits 2
Schmitt Trigger Input Yes
Propagation Delay 7.5ns
Current - Output High, Low 8mA, 8mA
Supply Voltage - Operating 2 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 006530-SN74AHC123APWR
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian SN74AHC123APWR CAD Model

Description

The SN74AHC123APWR is a high-quality, advanced dual retriggerable monostable multivibrator with reset from Texas Instruments.

  • Device Type: Dual Retriggerable Monostable Multivibrator
  • Features: Two internal one-shot circuits
  • Reset: Built-in active-low reset
  • tpd: maximum 13 ns
  • Functionality: Clear function
  • Triggering: Edge-triggered functionality
  • Voltage Range: 2V to 5.5V
  • Operating Temperature Range: -40°C to 85°C
  • Package: TSSOP (PW)
