The SN74ACT7204L25RJ is a high-speed, 25 MHz, 8-stage shift-and-store register bus counter designed and manufactured by Texas Instruments. This integrated circuit is part of the SN74 family, which is renowned for its reliability and performance in digital logic operations. The device is tailored for applications that require precise counting and timing solutions, such as industrial control systems, digital signal processing, and complex computing tasks.

Key Features

• High-Speed Operation: Capable of handling clock frequencies up to 25 MHz, making it suitable for high-performance applications.
• Logic Family: Operates within the ACT logic family, known for its advanced CMOS technology that offers a good balance between speed and power consumption.
• Supply Voltage: Designed to work with a supply voltage range of 4.5V to 5.5V, providing compatibility with standard TTL levels.
• Output Capability: Features 3-state outputs that facilitate bus-oriented applications, allowing multiple devices to share a common bus line without interference.
• Package: Comes in a robust and compact 32-lead PLCC (Plastic Lead Chip Carrier) package, denoted by the suffix 'RJ' in its product code, ensuring a small footprint on printed circuit boards.

Applications

The SN74ACT7204L25RJ is engineered to meet the demands of a wide array of applications, including:

• Industrial automation and control systems
• Professional digital audio and video equipment
• Communication infrastructure
• Data acquisition systems
• High-speed digital signal processing

Quality and Support

Texas Instruments is committed to delivering high-quality products and the SN74ACT7204L25RJ is no exception. Customers can expect comprehensive technical support and resources, including detailed datasheets, application notes, and design tools to facilitate the integration of this counter into their projects. With its robust design and versatile features, the SN74ACT7204L25RJ is an excellent choice for designers looking to implement a reliable and efficient counting solution in their electronic systems.
