PCA9534ARGTR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of I/O 8
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 10mA, 25mA
Max Frequency 400kHz
Supply Voltage - Operating 2.3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-QFN (3x3)
Win Source Part Number 026457-PCA9534ARGTR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCA9534ARGTR CAD Model

Description

The PCA9534ARGTR is a high-quality, high-performance product from Texas Instruments, a leading global semiconductor company that designs, manufactures, tests, and sells analog and embedded processing chips.

  • Product: PCA9534ARGTR
  • Manufacturer: Texas Instruments
  • Description: Remote 8-Bit I/O Expander with an I2C and SMBus interface
  • Operating Voltage: 2.3V to 5.5V
  • Function: 8-bit General Purpose I/O (GPIO) port expansion with interrupt and reset functions
  • Interface: I2C and SMBus interface
  • Feature: Active LOW reset input
  • Package: 16-pin TSSOP package
  • Feature: Built-in protection against electrostatic discharge and latch-up
