Same model may have multiple batches, images only for reference.

OPA277U

Name: OPA277U
Brand: Texas Instruments
SKU: 263562
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	OPA277U
Manufacturer	Texas Instruments
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP GP 1MHZ 8SOIC
Datasheet	OPA277U Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Amplifier Type	General Purpose
Number of Circuits	1
Slew Rate	0.8 V/μs
Gain Bandwidth Product (GBP)	1MHz
Current - Input Bias	500pA
Voltage - Input Offset	20μV
Operating Supply Current	790μA
Channel Output Current	35mA
Supply Voltage - Operating	4 V to 36 V, ±2 V to 18 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	090471-OPA277U
Family Name	OPA277
Introduction Date	April 01, 2006
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2028
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Test & Measurement, Portable Devices, Signal Processing
Ultra Librarian 3D Model	Ultra Librarian OPA277U CAD Model

Alternative Products

Description

The OPA277U is a high-performance operational amplifier (op-amp) from Texas Instruments, a renowned global semiconductor company.

Offset Voltage and Drift: Ultra-low
Gain-Bandwidth Product: 8 MHz
Slew Rate: 2.3 V/µs
Noise Density: 8nV/√Hz @ 1kHz
Single Supply Voltage: 4.5V up to 36V
Dual Supplies: ±2.25V to ±18V
Open-Loop Gain: 120 dB
Package: 8-pin SOIC
Operating Temperature Range: -40°C to +85°C
