Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Texas Instruments
Series Boomer
Part Status Obsolete(EOL)
Amplifier Type Class AB
Output Type 1-Channel (Mono) with Mono Headphones
Max Output Power x Channels @ Load 1W x 1 @ 8 Ohm; 90mW x 1 @ 32 Ohm
Operating Supply Voltage 2.2 V ~ 5.5 V
Board Type Fully Populated
Utilized IC / Part LM4892
Supplied Contents Board(s)
Win Source Part Number 779258-LM4892MBD
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM4892MBD CAD Model

Description

The LM4892MBD is an audio power amplifier designed by Texas Instruments for portable applications. It is a member of the Boomer® series, which are high-quality audio amplifiers optimized for mobile devices. The LM4892MBD delivers 1 watt of continuous average power to an 8-ohm load with less than 1% distortion (THD+N) from a 5V DC power supply, making it an ideal choice for providing high-quality sound output in portable electronic devices.

Key Features

  • Output Power: Delivers 1W into an 8Ω load at 5V.
  • Low Distortion: Maintains a THD+N of
  • Low Voltage Operation: Can operate on power supply voltages as low as 2.2V, suitable for battery-powered devices.
  • Shutdown Mode: Features a shutdown mode that reduces power consumption when not in use.
  • External Gain Configuration: Allows for gain adjustments through external gain-setting resistors.

Applications

The LM4892MBD is versatile and can be used in a variety of portable audio applications. These include:

  • Mobile Phones
  • Portable Media Players
  • Handheld Gaming Devices
  • Laptop and Notebook Computers
  • PDAs and Portable Organizers

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability. The LM4892MBD is built to meet the rigorous standards expected of TI products, ensuring long-term performance and stability in demanding portable applications.

Package Information

The LM4892MBD comes in a compact 8-pin MSOP (Micro Small Outline Package) that is conducive to space-constrained applications. Its surface-mount design allows for efficient assembly in high-volume production environments.

Support and Resources

For additional information, Texas Instruments provides extensive technical documentation, including datasheets, application notes, and design resources. Customers can also access TI's support community for further assistance with product integration and troubleshooting.
