ISO7240CDWR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002060-ISO7240CDWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name ISO724
Introduction Date August 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ISO7240CDWR CAD Model

Description

The ISO7240CDWR is a high-performance, quad-channel digital isolator product from Texas Instruments, a renowned global semiconductor company.

  • Configuration: Quad-channel, with two forward and two reverse-direction channels.
  • Data Rate: Up to 150 Mbps
  • Power Consumption: Low
  • Supply Range: 2.7 V to 5.5 V
  • Isolation Voltage: 4250 Vpeak
  • Package: Compact, surface-mount SOP-16 package
  • RoHS Compliant: Yes, free from lead, halogen and BFR
  • Operating Temperature Range: -40°C to +125°C
