Products specifications Report Issue?

Manufacturer Texas Instruments
Packaging Reel
Motor Type - AC, DC Brushed DC
Function Controller - Current Management
Output Configuration Pre-Driver - Half Bridge (2)
Interface Parallel
Technology Power MOSFET
Applications Use For General
Supply Voltage (V) 0V ~ 5.5V
Voltage - Load 5.9V ~ 45V
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 24-VFQFN Exposed Pad
Supplier Device Package 24-VQFN (4x4)
Manufacturer Pack Quantity 3,000
MSL Level 2 (1 Year)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 800942-DRV8701ERGER
Ultra Librarian 3D Model Ultra Librarian DRV8701ERGER CAD Model

Description

The DRV8701ERGER from Texas Instruments is a high-performance, brushed DC motor driver designed for powering motors in a wide range of applications. This integrated circuit (IC) offers a robust and efficient solution for driving single brushed DC motors. It is ideal for use in industrial, automotive, and consumer applications where reliable motor control is essential.

Key Features

  • Operating Voltage: The DRV8701ERGER operates over a wide supply voltage range from 6V to 28V, making it versatile for various applications.
  • Output Current: Capable of delivering up to 3.5A of continuous output current and 8A peak, it can drive a wide range of motors.
  • Integrated MOSFETs: The H-bridge motor driver includes integrated N-channel power MOSFETs, which provide high-performance and efficient motor control.
  • Protection Features: It comes with a suite of protection features including overcurrent, overtemperature, undervoltage lockout, and crossover-current protection, ensuring safe operation under various conditions.
  • Configurable Control: The device offers a PH/EN or PWM interface that allows for easy control of motor speed and direction.
  • Small Package: The DRV8701ERGER is available in a compact VQFN package, which is suitable for space-constrained applications.

Applications

The DRV8701E motor driver is perfect for a range of applications including:

  • Robotics and Automated Guided Vehicles (AGVs)
  • Power tools and lawn equipment
  • Industrial pumps and valves
  • Consumer electronics
  • Automotive accessories

Design Support

Texas Instruments provides extensive design support for the DRV8701ERGER with application notes, evaluation modules, and a comprehensive technical documentation to assist in the design and development process, ensuring a smooth integration of the motor driver into your project.
