Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology DMOS
Applications General Purpose
Output Current 2.8A
Supply Voltage - Operating 8 V to 38 V
Voltage - Load 8 V to 38 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 16-HTSSOP
Win Source Part Number 144190-DRV8800PWP
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Automation & Process Control, Sensing & Instrumentation
Ultra Librarian 3D Model Ultra Librarian DRV8800PWP CAD Model

Description

DRV8800PWP H-Bridge Motor Driver

The DRV8800PWP features an integrated H-bridge designed to drive brushed DC motors, solenoids, and other inductive loads. Its robust design and wide operating voltage range make it versatile for various power applications.

Features and Benefits

  • Single-bridge motor driver
  • Supports 8V to 36V operation
  • Low on-resistance for high efficiency
  • Protection features: Overcurrent, overtemperature, and under-voltage lockout

Applications and Projects

  • Home appliances
  • Automated window blinds
  • Commercial vending machines
  • Factory automation

The DRV8800 includes a comprehensive set of protection mechanisms to ensure reliable performance in demanding environments.
